Panic function D

Passage function

Use

For door systems that need to ensure temporary passage from inside and outside. To prevent the door from being opened from the outside after an escape door has been unlocked, the deadbolt must be locked again with the key. In principle, it is always possible to open the door from the danger side (emergency exit function).

Function on the danger side

There is a door handle or touch bar / push bar on the danger side. In the event of panic, the locked deadbolt can be retracted at the same time as the latch bolt via the door handle or touch bar / push bar. The lock is locked and unlocked with the key.

Function on the outside

There is a door handle on the outside. When locked, the handle is set to neutral. After an escape door has been unlocked, the latch can be retracted from the outside using the lever handle or the key via the change. The lock is locked and unlocked with the key.
